Symbol: 75B9H

Wheel diameter [mm]: 150

Wheel width [mm]: 39

Total height [mm]: 177

Load capacity [kg]: 200

Set/wheel weight [kg]: 1.90

Bolt hole spacing [mm]: 80x105 ø10

Offset [mm]: 150

Bearing type: Plain bearing

	Symbol							Bearing type	Bearing number
	75BNH Zobacz produkt	40	177	300	2.10	80x105 ø10	114	Ball bearing	6202
	75B9H Zobacz produkt	39	177	200	1.90	80x105 ø10	150	Plain bearing	-
