Symbol:
M72B2
Wheel diameter [mm]: 75
Wheel width [mm]: 2x26
Plate dimensions [mm]: 67x77
Total height [mm]: 103
Load capacity [kg]: 100
Set/wheel weight [kg]: 0.56
Bolt hole spacing [mm]: 48x55 ø8
Offset [mm]: 72
Bearing type: Plain bearing
Produkty podobne
Symbol: M72T2
Symbol: M52B2
Symbol: M52T2
Produkty dla średnicy
Symbol
Bearing type
M72T2
Zobacz produkt
2x25
67x77
103
100
0.59
48x55 ø8
72
Plain bearing
M72B2
Zobacz produkt
2x26
67x77
103
100
0.56
48x55 ø8
72
Plain bearing
×
