Symbol: 2252MŁ

Wheel diameter [mm]: 225

Wheel width [mm]: 71

Total height [mm]: 257

Load capacity [kg]: 100

Set/wheel weight [kg]: 3.50

Bolt hole spacing [mm]: 80x105 ø10

Offset [mm]: 180

Bearing type: Ball bearing

Symbol							Bearing type	Bearing number
2252ŁKX4 Zobacz produkt	70	257	100	2.50	80x105 ø10	180	Ball bearing	6001
2252M Zobacz produkt	71	257	100	3.20	80x105 ø10	180	Roller bearing	L-70
2252MŁ Zobacz produkt	71	257	100	3.50	80x105 ø10	180	Ball bearing	6004
2252 Zobacz produkt	70	257	95	2.55	80x105 ø10	180	Roller bearing	L-55
